Entanglement Trap Barrier Tank Tracks Wound Net Camouflaged Fence Tank Trap
MZP Putanka Wire | МЗП Путанка (inconspicuous obstacle, tanglefoot wire, confusion, Rabbit Wire) - a three-dimensional wire barrier made of carbon wire rings. The wire is very thin, so it is almost invisible. The task of the MZP wire of the muddle is to prevent it from approaching the object. A person falls into a trap of rings and, in most cases, will not be able to get out of it on their own. It takes a lot of time to cut a passage in the barrier. A Putanka inconspicuous obstacle is a serious obstacle for wheeled and tracked vehicles. Wire rings are wound around the wheels or tracks and stop the wheels from spinning.
Technical characteristics of an inconspicuous wire network
| Arameter |
Meaning |
| Unfolded dimensions |
10x10x1.4 m |
| Wire diameter / number of garlands |
0.9 mm / 20 pieces
0.8 mm / 20 pieces
0.6 mm / 20 pieces
0.5 mm / 20 pieces
twist - 0.8 mm |
| Folded dimensions |
1.2x0.6x0.8 m |
| Package weight without rings and peg |
24 kg |
| Complete set of the MZP package with rings and pegs |
40 pieces |
Measurements of the batch of MZP putanka
| Length(m) |
0.98 |
0.2 |
| Width(m) |
0.68 |
0.4 |
| Height( m) |
0.75 |
0.4 |
| Volume,(m³) |
0.4998 |
0.032 |
What happens when you hit an inconspicuous obstacle ?
If a person tries to go through into the territory, he gets confused in it. There is no way to get out of the confusion without outside help. Therefore, the offender remains safely waiting for the guard on the spot.
When an armored vehicle or tank passes, the vehicle wraps around the wheels and turns into a pile of metal on the chassis, preventing it from moving further. And it's difficult to remove such a gift from the wheels.
Features:
1. It has minimal visibility;
2. Is installed on any surfaces (horizontal and vertical);
3. The design of the set allows for quick installation and roll-up;
4. Can be equipped with additional security and notification systems.
Installation of an inconspicuous wire network
The Putanka package is deployed by 3 people in less than 20 minutes. When it is installed in the path of a possible intruder, a volumetric inconspicuous network 5 meters wide and 1.4 meters high is formed. Each package protects at least 10 meters of perimeter.
The Putanki package is deployed by 3 people in less than 20 minutes. When it is installed in the path of a possible intruder, a volumetric inconspicuous network 5 meters wide and 1.4 meters high is formed. Each package protects at least 10 meters of perimeter.
MZP putanka is installed by 4-8 people on the ground, on a fence, wall, roof of a building or structure.
In the lower tier there are garlands with a larger wire diameter.
The lower rings of an inconspicuous obstacle are attached to the ground with brackets and other devices every 1-2 meters along the perimeter of the barrier.
